15
Remove the doors
Tool required: Philips screwdriver, Flat bladed screwdriver.
z
Ensure the unit is unplugged and empty.
z
To take the door off, it is necessary to tilt the unit backwards. You
should rest the unit on something solid so that it will not slip during
the door removing process.
z
All parts removed must be saved to do the reinstallation of the
door.
z
Do not lay the unit flat as this may damage the coolant system.
z
It's better that 2 people handle the unit during assembly.
1.
Unscrew hinge cover by Philips
screwdriver.
2.
Disconnect the harness.
3.
Unscrew top hinge.
4.
Lift the door and place it on a
soft pad. Then remove another
door following same process.
5.
Unscrew bottom hinges.
6.
After the unit is positioned,
install the doors following the
same process but in reverse.
