92
MAINTENANCE
General Maintenance
NOTE: Do not touch a halogen bulb with bare fingers. Oil from skin
leaves a residue, causing a hot spot that will shorten the life
of the lamp.
Removing Halogen Bulbs
1. Remove the plenum covering
from t he headlight assembly.
2. Lift the rubber boot to expose
the bulb.
3. Push down on the spring (1)
to release it from the housing.
4. With the wire harness (2) attached
to the bulb (3), withdraw the bulb from the housing.
5. Grasp the bulb by its metal base and carefully separate the bulb
from the harness.
Installing Halogen Bulbs
1. Hold the bulb by its metal base and install it into the wire harness.
2. Insert the bulb into the housing.
3. Connect the spring to the housing.
4. Carefully flip the spring back into the housing, placing it around
the wire harness.
5. Reinstall the plenum covering on the headlight assembly.
6. Verify headlight aim.
Replacin g Taillight Bulb s
1. Remove the screws securing the
taillight lens.
2. Push the bulb i n and twist
counterclockwise and replace the bulb.
3. Replace the taillight lens.
