ENGINE AND COOLING
Engine Part Number Indy EVO: 1208630
RMK EVO: 1205790
Engine Model Number Indy EVO: S8630-5555-LL5T
RMK EVO: S5790-55555-LL5T
Displacement 544 cc
Cylinders 2
Bore x Stroke (mm) 73.0 x 65.0
Alternator Output 280 watt
Carburetor/Throttle Body 2-Mikuni®
Carburetor Model VM34
Idle RPM (+/- 200) 1700
Rated Operating RPM (+/- 200) 7000
Cooling Fan Air
Ignition Type Kokusan® 16 Bit ER
Ignition Timing 15° BTDC @ 1600 RPM / 14° BTDC @ 6500
RPM
Spark Plug / Gap NGK BR9ES / .028 in (0.70 mm)
Recommended Engine Oil Polaris Blue 2-Cycle Semi-Synthetic Oil
Recommended Fuel Octane Minimum 87 non-oxygenated
CARBURETOR SETTINGS
Main Jet 220
Pilot Jet 45
Jet Needle/Clip Position 6BGY48/#4
Needle Jet Q-0 (480)
Cutaway 3
Throttle Gap Under CA 6.98 mm / .275 in.
Fuel Screw (from fully seated) N/A
Air Screw (from fully seated) 1.5 Turns Fixed
Pilot Air Jet 2.5
130
SPECIFICATIONS
