REAR TRACK SHOCK SPRING (144)
Measure the rear track shock spring length and adjust to the appropriate length
based on rider weight. Include passenger weight (if applicable) and all riding
gear, accessories and cargo weight in the calculation.
WARNING
Allow a passenger to ride only on models equipped with a passenger seat.
1. Securely elevate and support the rear of the snowmobile to remove the
weight from the suspension.
2. Use a tape measure to measure the spring installed length between the two
spring retainers.
3. Refer to the chart on the next page to determine the correct spring length for
rider weight. If adjustment is needed, clear away any snow or ice trapped
within the spring or threads.
4. Using a spanner wrench, rotate the spring to adjust length.
NOTICE
Never adjust a spring beyond the maximum adjustment length shown in the
chart. Adjusting beyond maximum adjustment will cause the spring to bottom
and result in damage to your rear suspension.
Adjust the rear track shock spring per the charts on below.
EVO RMK MODELS
REAR TRACK SHOCK SPRING (RTSS) SET-UP
(Standard Spring)
Measure spring length with suspension off the ground
Rider Weight(including all riders,
gear, cargo, & accessories
Model Installed Spring Length(rear
suspension off the ground)
Shaded cells indicate factory settings.
< 160 lbs
< 73 kg
EVO RMK 9.5 in. 24.1 cm
160-220 lbs
73-100 kg
EVO RMK 9.12 in. 23.2 cm
220-280 lbs.
100-127 kg
EVO RMK 8.75 in. 22.2 cm
*RMK EVO maximum adjustment is 8.5 in. (21.6 cm)
36
THE PERFECT FIT
