Polaris 550 IQ Shift User Manual

38
THE PERFECT FIT
Handlebar Adjustments
When making handlebar adjustments, always be sure the handlebars,
brake lever and throttle lever operate smoothly and do not contact the
fuel tank, windshield or any other part of the vehicle when the handle-
bars are turned fully to the left or right.
Handlebar Position
Follow these steps to adjust handlebar position.
1. Remove the handlebar cover.
2. Loosen the four upper and four lower adjuster block bolts.
3. Adjust the handlebar to the desired position.
4. Torque the front bolts first, then torque the rear bolts. Torque the
bolts to 15-17 ft. lbs. (20-23 Nm).
5. Reinstall the handlebar cover.
Upper
Bolts
Lower
Bolts

Polaris 550 IQ Shift Specifications

General

Displacement	544 cc
Front Suspension	IQ
Rear Suspension	IQ
Cylinders	2
Cooling	Liquid
Track Length	121 in
Track Width	15 in
Front Travel	9 in (22.9 cm)
Rear Travel	13.9 in
Ski Type	Gripper
Ski Stance	42.5 in (108 cm)
