Polaris 550 IQ Shift User Manual

67
MAINTENANCE
Lubrication
Driveshaft Bearing
Inject grease into the fitting on the
speedometer sensor housing until
grease purges from the seal on the
inside of the tunnel. This should
take approximately two pumps. Do
not use more than four pumps.
Throttle Cable
Lubricate the throttle cable lightly
with grease or oil. With the engine
off, turn the handlebars to the left
and lubricate liberally as shown.
Choke and Choke Cable
Lubricate the choke slide and cables
lightly with oil or grease. Before
turning the engine off, operate the
choke intermittently to draw mois-
ture out of the choke plunger area
and reduce the possibility of the
choke becoming frozen.
H
H
H

Polaris 550 IQ Shift Specifications

General

Displacement	544 cc
Front Suspension	IQ
Rear Suspension	IQ
Cylinders	2
Cooling	Liquid
Track Length	121 in
Track Width	15 in
Front Travel	9 in (22.9 cm)
Rear Travel	13.9 in
Ski Type	Gripper
Ski Stance	42.5 in (108 cm)
