Polaris 550 IQ Shift User Manual

76
MAINTENANCE
Drive Chain Tension
Check drive chain tension weekly and
before each long trip. To obtain correct
chain tension:
1. Rotate the driven clutch counter-
clockwise to move all chain slack to
the tensioner side. Lock the brake
lever lock, or have an assistant hold
the brake lever firmly.
2. Loosen the adjuster bolt jam nut (1).
3. Finger tighten the adjuster bolt (2)
until it can no longer be adjusted by
hand, then back off 1/4 turn.
4. Tighten the jam nut while holding
the adjuster bolt. Torque to 21 ft.
lbs. (28 Nm).
5. Release the brake lever lock.
11
2

Polaris 550 IQ Shift Specifications

General

Displacement	544 cc
Front Suspension	IQ
Rear Suspension	IQ
Cylinders	2
Cooling	Liquid
Track Length	121 in
Track Width	15 in
Front Travel	9 in (22.9 cm)
Rear Travel	13.9 in
Ski Type	Gripper
Ski Stance	42.5 in (108 cm)
