THE PERFECT FIT
IQ Front Suspension Adjustments
Independent Front Suspension (IFS)
Break in the suspension for about 150 miles (240 km) before making
any fine-tuning adjustments.
Settings will vary from rider to rider, depending on rider weight,
vehicle speed, riding style, and trai l conditions. We recommend
starting with factory settings and then customizing each adjustment
individually to suit rider preference. The machine should be
methodically tested, one change at a time, under the same conditions
(trail and snow conditions, vehicle speed, riding position, etc.) after
each adjustment until the best ride is achieved.
IFS Components
1. Skis
2. Front shocks and springs
3. R od ends
4. Upper control arms
5. Lower control arms
IFS Adjustment Options
S Front shock spring preload
S Optional springs
S Optional shock valving (if
equipped with RydeFX shocks)
S Toe (ski alignment) (see page 110)
S Camber (see your dealer)
