THE PERFECT FIT
FAST M-10 Rear Suspension Adjustments
Ski Pressure
4. There are also two
front arm mounting
holes in the slide rail
that can adjust ski
pressure. The lower
hole (1) increases ski
pressure while the upper hole
(2) decreases ski pressure.
NOTE: By design, the BIASED COUPLE design of t he M-10
suspension displaces the rear arm as the front arm is
compressed. This means that when you raise the front
limiter strap, at some point you will collapse the rear
suspension arm, which will affect SAG height and reduce
rear suspension travel.
Initial M-10 Susp en s io n Set-up Chart
NOTE: The initial M-10 suspension set-up chart was not available at
the time of printing. Please see your Polaris dealer.
1
2
