Polaris 800 RMK 2011 User Manual

34
FEATURES
Instrument Cluster
Rider Information Center
The rider information center is located in the instrument cluster. The
center displays vehicle speed, engine speed, odometer, resettable trip
meters (2), total engine hours of operation, fuel level, engine tempera-
ture and diagnostic display mode.
Setting changes must be made with the engine running or with the vehi-
cle powered by an external DC power supply connector.
The information center is set to display standard units of measurement
for distance and temperature. To change to metric units, see page 38.
2
3
6
4
5
1

Polaris 800 RMK 2011 Specifications

General

Engine Type	Liberty
Displacement	795 cc
Track Length	155 in
Track Width	15 in
Track Height	2.4 in
Fuel Capacity	11.5 gal
Bore x Stroke	85 mm x 70 mm
Starter	Electric
Drive Clutch	P-85
Driven Clutch	Team LWT
Height	48 in
Front Travel	9 in
Rear Travel	16 in
Ski Type	Gripper
Carburetion	Mikuni
