Polaris 800 RMK 2011 User Manual

41
FEATURES
Instrument Cluster
Rider Information Center
Diagnostic Display Code Definitions
Diagnostic Codes
Component Condition SPN FMI
ECU Memory Checksum/CRC Error 628 13
Injector 1 (MAG) (Port Injector) Driver Circuit Open/Grounded 651 5
Driver Circuit Short to B+ 3
Injector 2 (PTO) (Port Injector) Driver Circuit Open/Grounded 652 5
Driver Circuit Short to B+ 3
Knock Sensor 1 Voltage Too Low 731 4
Ignition Coil Primary Driver 1 (MAG) Driver Circuit Open/Grounded 1268 5
Fuel Pump Driver Circuit Driver Circuit Open/Grounded 1347 5
Knock Level Cylinder 1 (MAG) Maximum Detonation
Correction Limit Reached
1352 0
Knock Above Critical Level 16
Knock Level Cylinder 2 (PTO) Maximum Detonation
Correction Limit Reached
1353 0
Knock Above Critical Level 16
Sensor Supply Voltage 1 (TPS/
TMAP Sensor Power)
Voltage Too Low 3509 4
Sensor Supply Voltage 2 (Ground
Speed Sensor)
Voltage Too Low 3510 4
ECU Output Supply Voltage 2 (Injec-
tion Supply PWR)
Voltage Too High 3598 3
Voltage Too Low 4
Throttle Release Signal Voltage Too High 520194 3
Voltage Too Low 4
Throttle Stuck 7
Chassis Relay Driver Circuit Open/Grounded 520208 5
Driver Circuit Short to B+ 3
Exhaust Valve Solenoid Driver Circuit Grounded 520215 5
Driver Circuit Short to B+ 3
Fuel Type Selected Voltage Too High 524007 3
Voltage Too Low 4
Signal Out Of Range 2

Polaris 800 RMK 2011 Specifications

General

Engine Type	Liberty
Displacement	795 cc
Track Length	155 in
Track Width	15 in
Track Height	2.4 in
Fuel Capacity	11.5 gal
Bore x Stroke	85 mm x 70 mm
Starter	Electric
Drive Clutch	P-85
Driven Clutch	Team LWT
Height	48 in
Front Travel	9 in
Rear Travel	16 in
Ski Type	Gripper
Carburetion	Mikuni
