43
THE PERFECT FIT
Suspension Adjustments
For riders who weigh 160-220 lbs. (73-100 kg), test ride at factory
settings, then make fine-tuning adjustments. See page 44.
For riders outside the 160-220 lbs. (73-100 kg) weight range, adjust the
factory-set preload to the following installed lengths as a starting point,
then test ride before making fine-tuning adjustments. Do not exceed the
minimum and maximum installed length requirements. See page 42.
TIP:If adjustments to the factory-installed springs are not sufficient for riders
over 300 lbs. (136 kg), optional heavy springs are available. Please see
your POLARIS dealer.
Initial RTSS Preload Settings
(Measure spring length with suspension off the ground)
Rider Weight Model Installed Length
For Factory-Installed Springs
Under 160 lbs. Under 73 kg RMK/PRO-RMK 10 3/4" 27.3 cm
ASSAULT RMK 10 7/8" 27.6 cm
160-220 lbs 73-100 kg RMK/ASSAULT
RMK
*10 1/4" *26 cm
PRO-RMK *10 3/8" *26.4 cm
220-280 lbs. 100-127 kg RMK/PRO-RMK 10 1/8" 25.7 cm
ASSAULT RMK 10" 25.4 cm
280-340 lbs. 127-154 kg RMK/PRO-RMK 9 3/4" 24.8 cm
ASSAULT RMK 9 1/2" 24.1 cm
*Factory Setting
For Optional 250-Pound Heavy Springs
250-300 lbs. 113-136 kg ALL 10 1/8" 25.7 cm
300-350 lbs. 136-159 kg ALL 10" 25.4 cm

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polaris 800 RMK 2011 and is the answer not in the manual?

Polaris 800 RMK 2011 Specifications

General IconGeneral
Engine TypeLiberty
Displacement795 cc
Track Length155 in
Track Width15 in
Track Height2.4 in
Fuel Capacity11.5 gal
Bore x Stroke85 mm x 70 mm
StarterElectric
Drive ClutchP-85
Driven ClutchTeam LWT
Height48 in
Front Travel9 in
Rear Travel16 in
Ski TypeGripper
CarburetionMikuni
