Polaris 800 RMK 2011 User Manual

47
THE PERFECT FIT
Handlebar Adjustments
Handlebar Position (if equipped)
1. Loosen the four bolts on the bottom of the adjuster block. If neces-
sary, pry the blocks apart with a screwdriver.
2. Adjust the handlebar forward or rearward to the desired position.
3. Tighten the bolts.
Handlebar Angle
1. Loosen the four bolts on the top of the adjuster block. If necessary,
pry the blocks apart with a screwdriver.
2. Adjust the handlebar forward or rearward to the desired angle.
3. Tighten the bolts.
Loosen top bolts to adjust
handlebar angle
Loosen bottom bolts to
adjust handlebar position
(if equipped)

Polaris 800 RMK 2011 Specifications

General

Engine Type	Liberty
Displacement	795 cc
Track Length	155 in
Track Width	15 in
Track Height	2.4 in
Fuel Capacity	11.5 gal
Bore x Stroke	85 mm x 70 mm
Starter	Electric
Drive Clutch	P-85
Driven Clutch	Team LWT
Height	48 in
Front Travel	9 in
Rear Travel	16 in
Ski Type	Gripper
Carburetion	Mikuni
