83
OPERATION
Throttle Lever
Throttle Lever Freeplay Adjustment
Adjust throttle lever freeplay using the in-line throttle cable adjuster.
1. Locate the in-line adjuster on the throttle cable.
2. Loosen the lock nut.
3. Rotate the adjuster clockwise to DECREASE freeplay. Rotate the
adjuster counter-clockwise to INCREASE freeplay.
4. When freeplay is adjusted to .009-.029 in. (0.25-0.76 mm), tighten
the lock nut against the adjuster.
5. Start the engine and allow it to idle.
6. Turn the handlebar to the full left and full right positions. Verify that
engine RPM does not increase as the handlebar is turned. If engine
RPM increases, the throttle lever freeplay is too tight and must be
readjusted.
WARNING! Do not operate the snowmobile if throttle cable freeplay is too tight.
Lock
Nut
In-Line
Adjuster
