Polaris 850 PRO-RMK 163 3.0" QD 2021 - Console Assembly View

9
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
9.13
CONSOLE ASSEMBLY VIEW
q
Console
t
Recoil Bracket
w
Foam, Console – LH
y
Screws (10 x 5/8)
e
Foam, Console – RH Upper
u
Plastic Rivets
r
Foam, Console – RH
CHASSIS
