66
MAINTENANCE
Gearcases
Gearcase Specification Chart
Transmission (Main Gearcase)
Always check and change the transmission oil at the intervals outlined in the Periodic
Maintenance Chart beginning on page 59. Refer to the Gearcase Specifications Chart for
recommended lubricants, capacities and torque specifications. See page 92 for the part
numbers of POLARIS products.
Gearcase Lubricant Capacity Fill Plug Torque Drain Plug Torque
Main Gearcase
(Transmission)
AGL Gearcase
Lubricant &
Transmission Fluid
44 oz.
(1300 ml)
10-14 ft-lbs
(14-19 Nm)
10-14 ft-lbs
(14-19 Nm)
Front Gearcase Demand Drive Fluid 7.5 oz.
(222 ml)
8-10 ft-lbs
(11-14 Nm)
8-10 ft-lbs
(11-14 Nm)
Gearcase
