90
SPECIFICATIONS
POLARIS GENERAL 1000 EPS / EPS DELUXE
Maximum Weight Capacity (including
operator, passenger, cargo, non-factory
installed accessories)
1030 lbs. (467 kg)
Dry Weight 1430 lbs. (649 kg) (EPS)
1491 lbs. (676 kg) (EPS w/Winch and Aluminum Wheels)
1544 lbs. (700 kg) (EPS Deluxe)
Test GVW - Rollover Protection System
(ROPS)
2796 lbs. (1268 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 9.5 gal. (36 L)
Engine Oil Capacity 2.5 qts. (2.4 L)
Coolant Capacity 5.44 qts. (5.1 L)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 600 lbs. (272 kg)
Overall Length 116 in. (294.6 cm) (EPS)
118 in. (299.7 cm) (EPS w/Winch and Aluminum Wheels)
118 in. (299.7 cm) (EPS Deluxe)
Overall Width 61.5 in. (156.2 cm)
Overall Height 76 in. (193 cm)
Wheelbase 81 in. (205.7 cm)
Cargo Box Dimensions (Inside) 26 x 43 x 11 in. (66 x 109 x 28 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 190 in. (483 cm)
Engine 4-Stroke DOHC Twin Cylinder
Displacement 999 cc
Bore x Stroke 93 mm x 73.5 mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System Electronic
Spark Plug / Gap MR7F / 0.7-0.8 mm
Front Suspension Independent Double A-arm w/12.25 in. (31 cm) of travel
Rear Suspension Independent Double A-arm w/13.25 in. (33.7 cm) of travel
Lubrication System Wet Sump
