87
MAINTENANCE
Lights
Brake Lights
When the brake pedal is depressed, the console brake light comes on.
Check the brake light before each ride.
1. Turn the ignition switch to the ON position.
2. Depress the brake pedal. The brake light should come on after about
10mm (0.4 in.) of pedal travel. If the light doesn't come on, check
the bulb.
Indicator Lamp Replacement
1. Lift the hood.
2. Reach in behind the console
panel and lift the release to
unplug the light from the
harness.
3. Using a flathead screwdriver,
press on the tab on the top of
the light to remove the indi-
cator light assembly from the
console panel.
4. Locate the expired lamp. Using a screwdriver, rotate the lamp 1/4
turn counterclockwise.
5. Grip the lamp with a needle-nose pliers and remove it from the
assembly.
6. Install the new lamp. Using a screwdriver, rotate the lamp 1/4 turn
clockwise to seat it.
7. Snap the assembly back into the console panel. Reconnect the har-
ness.
8. Close the hood.
Ta b
Release
