FUSES
If the engine stops or will not start, or if you experience other electrical failures, a
fuse may need replacement. Locate and correct any short circuits that may have
caused the blown fuse, then replace the fuse.
The fuse box is located in the electrical compartment under the left rearmost
seat. Spare fuses are provided in the fuse box.
If you suspect that a fuse or relay may not be working properly, your dealer can
assist.
FUSE SIZE FEATURE SUPPORTED
5A Brake Light
10A Drive System, Fuel Pump
20A EFI, Power Steering (if equipped),
Lights, Accessories
20A Circuit Breaker Fan
FUSE BOX DIAGRAM
HEAD-
LIGHT
RELAY
FAN
RELAY
EFI RELAY
FUEL
PUMP
RELAY
CHASSIS
RELAY
SPARE
5A
SPARE
10A
EPS
RELAY
(OPT)
FAN
20A CB
EFI
20A
FUEL
PUMP
10A
BRAKE
LIGHT
5A
SPARE
20A
EPS (OPT)
20A
LIGHTS
20A
DRIVE
10A
ACCY
20A
111
MAINTENANCE
