RANGER 570/570 EPS RANGER CREW 570/570
EPS
Maximum Weight Capacity
(includes weight of
operator, passenger,
cargo, accessories)
1000 lbs. (454 kg) 1250 lbs. (567 kg)
Dry Weight 1075 lbs. (488 kg) (570)
1100 lbs. (499 kg) (570
EPS)
1140 lbs. (517 kg) (570 w/
park brake)
1323 lbs. (600 kg) (570)
1352 lbs. (613 kg) (570
EPS)
Test GVW - Rollover
Protection System (ROPS)
2255 lbs. (1023 kg) per
OSHA 29 CFR 1928.53
2700 lbs. (1225 kg) per
OSHA 29 CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 l) 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l) (570) 2 qts. (1.9 l)
Coolant Capacity 120 oz. (3.5 l) 170 oz. (5 l)
Overall Length 110 in. (279.4 cm) 142 in. (360.7 cm)
Overall Width 58 in. (147.3 cm) 60 in. (152.4 cm)
Overall Height 73 in. (185 cm) 73 in. (185 cm)
Wheelbase 73 in. (185 cm) 73 in. (185 cm)
Cargo Box Dimensions
(Inside)
32x42x11.5 in. (81x107x29
cm)
32x42x11.5 in. (81x107x 9
cm)
Ground Clearance 10 in. (25.4 cm) 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm) 237 in. (602 cm)
Towing Capacity 1500 lbs. (680.4 kg) 1500 lbs. (680.4 kg)
Hitch Tongue Capacity 150 lbs. (68 kg) 150 lbs. (68 kg)
Max. Cargo Box Load 500 lbs. (227 kg) 500 lbs. (227 kg)
Engine Dual overhead cam, 4 valve 4 stroke single cylinder.
Displacement 567 cc (570)
Bore x Stroke (mm) 99mm x 73.6mm (570)
Alternator Output 560 W @ 3000 RPM
Compression Ratio 10:1 (570)
127
SPECIFICATIONS
