Page #559 background imageLoading...
Page #559 background image
12
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
12.27
4. Each test should measure: Open Line (OL)
TEST
CONNECT
METER
LEADS TO:
OHMS
READING
Battery Charge
Coil
Y1, Y2, or Y3
to Ground
Open Line
(Infinity)
NOTICE
Any measurement other than Infinity (open) will indicate
a failed or shorted stator leg.
TEST 3: Measure AC Voltage Output of Each
Stator Leg at Charging RPM
5. Set the selector dial to measure AC Voltage.
6. Start the engine and let it idle.
7. While holding the engine at a specified RPM,
separately measure the voltage across each ‘leg’ of
the stator by connecting the meter leads to the wires
leading from the alternator (Y1 to Y2, Y1 to Y3, Y2 to
Y3).
8. Refer to the following table for approximate AC
Voltage readings according to RPM. Test each leg at
the specified RPM in the table.
9. Example: The alternator voltage output reading
should be approximately 18 VAC at 1300 RPM
between each ‘leg’.
NOTICE
If one or more of the stator leg output AC voltage varies
significantly from the specified value, the stator may
need to be replaced.
RPM READING
AC VOLTAGE (VAC)
READING
1300 21 VAC ± 25 %
3000 49 VAC ± 25 %
5000 80 VAC ± 25 %
ELECTRICAL
