8.6
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
9. Rotate hub. It should rotate smoothly without binding
or rough spots or side play.
10. Install brake caliper using new bolts
q
. Tighten bolts
to specified torque.
TORQUE
Brake Caliper Bolt Torque:
46 ft-lbs (62 Nm)
CAUTION
New brake disc bolts have a pre-applied locking agent
which is destroyed upon removal. Always use new
brake disc mounting bolts upon assembly if removed.
11. Install wheel, washers, wheel nuts, and tighten
evenly in a cross pattern to specified torque.
Refer to “Torque Specifications”.
FINAL DRIVE
