34
FEATURES AND CONTROLS
Instrument Cluster
Indicator Lamps
Rider Information Center
The rider information center is
located in the instrument cluster.
All segments will light up for one
second at start-up.
If the instrument cluster fails to
illuminate, a battery over-voltage
may have occurred and the
instrument cluster may have shut
off to protect the electronic
speedometer. If this occurs, your
POLARIS dealer can provide
proper diagnosis.
The information center is set to
display standard units of
measurement and a 12-hour clock
at the factory. To change to metric
and/or a 24-hour clock, see page
36.
Lamp Indicates Condition
Vehicle Speed
When standard mode is selected, speed displays in miles per hour.
When metric mode is selected, speed displays in kilometers per hour.
Over Temperature This lamp illuminates to indicate an overheated engine. If the
indicator flashes, the overheating condition remains, and the system
will automatically reduce engine power.
EPS Warning (if
equipped)
This indicator illuminates briefly when the key is turned to the ON
position. If the light remains on, the EPS system is inoperative. Your
POLARIS dealer can assist.
Neutral This lamp illuminates when the transmission is in neutral and the
ignition key is in the ON position.
High Beam This lamp illuminates when the headlamp switch is set to high beam.
Helmet/Seat Belt The lamp is a reminder to the operator to ensure all riders are
wearing helmets and seat belts before operating. The driver's seat
belt is equipped with a seat belt interlock. Vehicle speed will be limited
to 15 MPH (24 km/h) if the seat belt is not secured.
Check Engine This indicator appears if an EFI-related fault occurs. Do not operate
the vehicle if this warning appears. Serious engine damage could
result. Your POLARIS dealer can assist.
