96
SPECIFICATIONS
RANGER CREW 900
Maximum Weight Capacity 1750 lbs. (795 kg) (including operator, passengers, cargo, accessories)
1350 lbs. (612 kg) (Models sold in California)
Dry Weight 1570 lbs. (712 kg)
Test GVW - Rollover Protection
System (ROPS)
3600 lbs. (1633 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 10 gal. (37.8 l)
Engine Oil Capacity 2.5 qts. (2.4 l)
Coolant Capacity 5 qts. (4.75 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 1000 lbs. (454 kg)
600 lbs. (272 kg) (Models sold in California)
Overall Length 148 in. (376 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 113 in. (287 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 12 in. (30.5 cm)
Min. Turning Radius 214 in. (543.5 cm)
Engine 4-Stroke DOHC Twin Cylinder
Displacement 875 cc
Bore x Stroke 93mm x 64.4mm
Alternator Output 575 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System Electronic
Spark Plug / Gap XG4YCX / 0.7-0.8 mm
Front Suspension Dual A-arm w/10 in. (25.4 cm) of travel
Rear Suspension Independent w/10 in. (25.4 cm) of travel
Lubrication System Wet Sump
