77
MAINTENANCE
Lubrication
n Chaincase Oil
Check the chaincase oil level at the
intervals outlined in the maintenance
charts beginning on page 71. The sight
glass is located on the lower rear of the
chaincase. Maintain the oil level at or
slightly below the center of the sight
glass. Change the chaincase oil after the
first 500 miles (800 km), then every
1000 miles (1600 km) or seasonally.
Polaris recommends the use of Polaris
Synthetic Chaincase Lube. See page 112
for the part numbers of Polaris products.
Oil Check
1. Position the vehicle on a level sur-
face.
2. View the oil level at the sight glass.
3. Remove the fill plug and add the
recommended oil as needed. Do not
overfill.
4. Reinstall the fill plug, making sure it
is seated properly.
Maintain Level Here
Sight Glass
Fill
Plug
