9
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
9.41
25.Install piston bearing on installation tool.
26.Place installation tool assembly on top of the piston
and push down to install bearing.
NOTICE
Bearing will be fully seated around piston when done
correctly.
27.Install compression side valve stack.
NOTICE
When installing bleed shim, ensure the tab is lined up
with compression port.
28.Install rebound valve stack with required top out
washer.
29.Apply a thin layer of float fluid to the threads, nut, or
BOC post and torque to 22 ft-lbs (30 Nm).
STEERING / SUSPENSION
