29
FEATURES AND CONTROLS
Passenger Hand Hold
Always adjust the hand hold to a comfortable position for your
passenger before operating. Make sure the adjustment pin and retainer
are securely installed after making adjustments.
1. Remove the retainer from the end of the adjustment pin.
2. Remove the pin from the post.
3. Slide the post inward or outward to the desired position.
4. Reinstall the pin through the post mounting hole, adapter bushing
hole, both post adjustment holes and lastly through the remaining
bushing hole and post mounting hole.
5. Reinstall the retainer to the pin.
A
d
j
u
s
t
m
e
n
t
P
o
s
i
t
i
o
n
H
o
l
e
s
Post Mounting
Holes
Adjustment
Pin
Pin
Retainer
Adapter
Bushing
