89
MAINTENANCE AND LUBRICATION
Adjustments
WARNING
Improper adjustment of the handlebars or incorrect torquing of
the adjuster block tightening bolts can cause limited steering or
loosening of the handlebars, resulting in loss of control and
possible serious personal injury or death. Follow the adjustment
procedures exactly, or see your Polaris dealer for service.
Handlebars
The handlebars can be adjusted for
rider preference.
1. Remove the handlebar cover.
2. Loosen (do not remove) the
four handlebar bolts.
3. Adjust the handlebar to the
desired height. Be sure the
handlebars do not contact the gas
tank or any other part of the
machine when t urned fully to the
left or right.
4. Torque the front two bolts (A) to
10-12 ft. lbs. (14-17 Nm), then
torque the rear two bolts (B). A
gap of up to 1/8” (3 mm) will
remain at the rear bolts.
A
B
