ENGINE
2.7
15. Remove the stator gasket, clean the area
thoroughly. Loosen and remove the oil pump.
The oil pump slides out in the forward direction.
OIl Pump
16. Use the oil pump drive gear removal tool to
remove the oil pump drive gear.
Oil Pump Drive Gear Removal Tool:
(PN 0450699)
17. Remove the oil seal bracket.
NOTE: To ease disassembly, clean the grease out of
the oil pump chamber area and note the amount. That
same amount of greaseis reinserted into the chamber
later in the engine assembly.
18. Remove the dowel pin from the crankshaft.
19. Remove the external circlip from the crankshaft.
20. Remove the circlip to disassemble the oil pump
gear.
OIl Pump
