129
MAINTENANCE
Spark Arrester
Arrestor Cleaning (SCRAMBLER)
If your model is equipped with dual exhaust, periodically perform the
following procedure for both arresters to remove accumulated carbon.
1. Remove the retaining nut. Remove the arrester from the end of the
muffler.
2. Use a non-synthetic brush to clean the arrester screen. A synthetic
brush may melt if components are warm. If necessary, blow debris
from the screen with compressed air.
3. Inspect the screen for wear and damage. Replace a worn or
damaged screen.
4. Reinstall the arrester. Torque the nut to 10-12 Nm.
