150
SPECIFICATIONS
* Based on EU Directive 76/432/EC
SPORTSMAN 1000 / SPORTSMAN XP 1000
Maximum Weight Load Capacity 261 kg
Dry Weight 378 kg +/- 5 %, based on configuration (1000)
398 kg +/- 5 %, based on configuration (XP 1000)
Fuel Capacity 20 L
Engine Oil Capacity 1.9 L
Coolant Capacity 1.9 L
Rear Gearcase Oil Capacity 210 ml
Demand Drive Fluid Capacity 275 ml
Transmission Oil Capacity 1100 ml
Front Rack/Storage Box Capacity 55 kg
Rear Rack Capacity 110 kg
Hitch Tongue Weight 75 kg (Rear rack capacity and tongue weight not
to exceed 75 kg)
Hitch Towing Rating 750 kg on level ground
Unbraked Trailer Towing
Capacity*
868 kg
Overall Length 211 cm
Overall Width 121 cm
Overall Height 129 cm
Wheelbase 134.6 cm
Ground Clearance 29.5 cm
Minimum Turning Radius 213 cm unloaded
Fuel System Bosch Multi-Port Sequential Electronic Fuel
Injection
Fuel Delivery Electronic Fuel Pump (in tank)
Engine EHO952LE
Displacement 952 cc
Engine Power 65.6 kW
Bore x Stroke 90.5 x 74
Alternator Output 475w @1200 RPM/Peak 575w
Compression Ratio 11:1
Starting System Electric
Ignition System Electronic Fuel Injection
Idle RPM 1200 +/- 50
Ignition Timing 6 +/- 5 BTDC @ 1200 RPM, Engine warm
Throttle Body/Size Mikuni Dual Bore/42 mm
Spark Plug Type / Gap AUTOLITE 5682 / 0.76 mm
Throttle System Electronic Throttle Control (ETC)
Lubrication System Wet Sump
