Polaris Sirius-3 Navtex 3-Frequency - GPS Connection

Sirius-3 Navtex 3-Frequency
-
21
GPS Connection (NMEA 0183)
Use the NMEA port to connect a GPS. The sub-D pins are to be
connected as described below.
When a GPS is connected UTC is automatically updated.
Sirius-3 will receive the information from these NMEA sentences:
- RMC (Time and Date)
- GGA (Position)
NMEA 0183 port pin
-
out
Pin Number
Connection
Notes
1
GND
Ground
2
NC
No Connection
3
NC
No
Connection
4
TX+
Option
5
TX
-
Option
6
NC
No Connection
7
NC
No Connection
8
RX
-
NMEA 0183 Input
-
9
RX+
NMEA 0183 Input
+
