Sirius-3 Navtex 3-Frequency

Alarm Relay Connection

When an alarm is received an internal relay is pulled and a

connection between pin 3 and 7 is made.

ECDIS port, Alarm Relay and Mute

out

Pin Number

Connection

Notes

GND

Ground

Mute A

Mute Input +

Alarm com

Alarm relay

TX+

IBS port Output

Mute B

Mute Input

Alarm No

Alarm relay

IBS port Input

AUX Connection

This port is used for special applications only.
