70
MAINTENANCE
Battery
Battery Access and Removal
The battery compartment is located on the
lower left side of the vehicle, behind the rider
compartment.
1. Remove the access panel fasteners and
remove the access panel.
2. Remove the battery retainer nut. Remove
the retainer wedge from the stud.
3. Slide the battery out of the compartment.
4. Remove the nut securing the negative (-)
battery cable to the chassis ground.
Remove the cable eyelet from the stud.
Move the cable to prevent it from
contacting any metal components.
5. Loosen the positive (+) battery terminal
bolt and disconnect the cable from the
terminal. Move the cable to prevent it
from contacting any metal components.
