CLUTCHING
ALTITUDE SHIFT WEIGHT
DRIVE CLUTCH
SPRING
DRIVEN
CLUTCH
SPRING
Meters (Feet)
0-1800
(0-6000)
25–48
PN 5633217
Red/Blue
PN 7043372
Black
PN 7041782
1800-3700
(6000-12000)
28–36
PN 5633115
Blue/Red
PN 7043199
Black
PN 7041782
SPORTSMAN 450 HD 2X4
SPORTSMAN 450 HD 2X4
Maximum Weight Capacity 485 lbs. (220 kg) (operator, cargo, accessories)
Dry Weight 640 lbs. (290 kg)
Fuel Capacity 4.5 gal. (17 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2.7 qts. (2.5 l)
Rear Gearcase Oil Capacity 7.1 oz. (210 ml)
Demand Drive Fluid Capacity 9 oz. (265 ml)
Transmission Oil Capacity 32 oz. (948 ml)
Front Rack/Storage Box Capacity 90 lbs. (40.8 kg)
Rear Rack Capacity 180 lbs. (81.6 kg)
Receiver Hitch Tongue Capacity 120 lbs. (54 kg) (Rear rack capacity and tongue
weight not to exceed 180 lbs./81.6 kg)
Hitch Towing Rating 1225 lbs. (555.7 kg)
Unbraked Trailer Towing Capacity* 1786 lbs. (810 kg)
Overall Length 83 in. (211 cm)
Overall Width 48 in. (122 cm)
Overall Height 46 in. (117 cm)
Wheelbase 50.5 in. (128.3 cm)
Ground Clearance 10 in. (25.4 cm)
Minimum Turning Radius 65 in. (165 cm) unloaded
131
SPECIFICATIONS
