Polaris ToyotaLUXX Installation Manual

1300 555 514 4
Installaon Notes
 Whilst most of this unit is classied as plug and play, it does not necessarily mean it is going to be a
breeze. Some things may have to be modied or you may have to tap into wires
depending on your vehicle.
 The wiring and installaon of this unit requires special technical skill and experience. If you do not
feel condent installing this product or do not have the level of skill necessary, please
contact Polaris on 1300 555 514 so we can refer to a recommended installer.
 The ToyotaLUXX has transportaon screws in the top of the unit—please remove these
before installaon
 Unfortunately we do not have the colour codes of every vehicle. To nd the correct wires to tap in-
to, our installers use the following items:
- Test lamp (to nd power).
- Mulmeter (to nd steering wheel control wires).
- 9 volt baery (to nd the speaker wires).
 This unit is designed to be used in a vehicle with a 12 volt baery and a negave grounding. Before
installing this unit to a recreaonal vehicle, bus, or truck, make sure the baery
voltage is appropriate for this unit to be used. If installing into a 24Volt vehicle , you will need a 10
amp converter which can be purchased through automove electronic shops such as Jaycar
electronics.
 To avoid short circuit in the electrical system, ensure that the negave baery cable is
disconnected before installaon.
 To avoid possibility of shorng out the electrical circuit in the unit, never connect the baery wire
directly to the vehicle baery.
 Always secure all wirings with cable clamps or adhesive tape to prevent short circuit.
 Please make sure all wiring connecons and speaker wires are well insulated.
 When pulling the dash apart, please use quality trim tools to avoid damaging your dash.
 Please do NOT cut any plugs o of any Polaris cameras. Doing so will void your warranty! If you
need to blend other brand cameras into our system, please call Polaris on 1300 555 514 so we can
refer you to a recommended dealer who has the skill and experience in performing this type of
work.
 Some vehicles will require extra parts such as:
- Fascia's to make it t nice and neatly.
- CAN bus modules to retain steering wheel controls or other original features of the car.
- modules to retain a factory amp.
 If there is something you are not 100% sure about when installing this unit, please give our
experienced technicians a call on 1300 555 514.

Polaris ToyotaLUXX Specifications

General

Brand	Polaris
Model	ToyotaLUXX
Category	Car Navigation system
Language	English
