Final Drive / Propulsion
5.25
Dr iveshaft Lubrication -- Continued
6. Reposition driveshaft shroud (open side down) and
torque clamp screw to specifications.
7. Reconnect battery ground (--) cable.
8. Reinstall seat.
Bearing Housing Removal / Inspection
1. With driveshaft and pump removed, loosen
clamps securing housing assembly to through-hull
fitting.
Front of Watercraft
Engine
Grease Fitting
Bearing Housing
Drive Shaft Shroud Clamp Torque
20-25 in. lbs. (2.3-2.9 Nm)
Grease
Front of Craft
Coupler Shroud
Engine
To Next Page
