35
THE PERFECT FIT
Handlebar Adjustments
Standard Handlebar
Follow these steps to adjust handlebar angle at the handlebar block.
1. Remove the mountain bar by
removing nuts.
2. Using a 7/16-inch wrench,
loosen the four nuts on the
bottom of the adjuster block
(turn the handlebar either left
or right for access to the rear
nuts). If necessary, pry the
blocks apart with a screw-
driver.
3. Adjust the handlebar to the
desired angle. Be sure the
handlebar, brake lever and
throttle lever operate
smoothly and do not hit the
gas tank, windshield or any
other part of the snowmobile
when the handlebar is turned
fully to the left or right.
4. Torque the front bolts first, then torque the rear bolts. Torque the
bolts to 11-13 ft. lbs. (15-18 Nm).
5. Reinstall the mountain bar.
