Parts and Controls
1. Auto-Focus Window 12. Film Rewind Shaft
2. Shutter Release Button 13. Flash Ready Light
3. Viewfinder Window 14. Viewfinder Eyepiece
4. Red-Eye Reduction Light 15. Film Take-Up Spool
5. Auto-Flash Sensor 16. Back Cover
6. Film Counter Window 17. Film Check Window
7. Built-In Auto Flash 18. Strap Eyelet
8. Lens Cover 19. Battery Compartment Cover
9. Lens 20. Tripod Socket
10. Lens Cover Switch 21. Film Rewind Switch
11. Back Cover Latch 22. Film Chamber
Insert the loop at the end of the strap
under the strap eyelet (18) (Fig. 1).
1
2
3
4
5
6
7
8
9
10
12
22
13
14
15
16
17
18
21
19
20
11
Attaching the Strap
