System Connections
11
S-VIDEO:
S-
VIDEO OUTPUT:
Insert the S-video cable (not included) into the S-video output (#3) on the rear panel of your
DVD Recorder.
Connect the other end of the S-video cable to the corresponding input on your TV.
S-VIDEO INPUT:
Using the S-video cable coming from your AV equipment (ie. set-top box, cable box, satellite
box, VCR, etc), connect the other end of the S-video cable to the S-video input (#7) on the rear
panel of your DVD Recorder.
Note: do not connect the yellow composite video cable if you are using the S-video input.
•
•
•
•
