28
Chapter 3 Using the LCD TV
Press the PIP button again to view images side by side.
▪ Press ◄ ► to toggle the audio source between the main window and the sub window.
▪ Press the OK button to swap the pictures between the main and sub windows.
SubMain
▪ Press ◄ ► to activate either the main or sub window, then press the Input button to
display the Input List:
Press ▲▼ to change input source and press the OK button.
NOTE: PIP does not function when VIDEO4 (YPbPr1) and VIDEO5 (YPbPr2) inputs are selected
together.
Press the PIP button again to exit.
Sub
TV(CABLE/AIR)
VIDEO1 (SIDE)
VIDEO2 (REAR)
VIDEO3 (S-VIDEO)
VIDEO4 (YPbPr1)
VIDEO5 (YPbPr2)
COMPUTER (VGA)
To Next Page
