Instruction ManualManual
Remote Control Features
Front panel
Rear p
anel
Front and Rear Unit Profiles
ANTENNA IN
6
1 2 3 4 5 6 7 8 9 10 1112 13 14 15 161718 19 20
1 AV IN1 JACK 7 REC/OTR 13 VOLUME DOWN/UP
2 VCR DECK 8 TIMER REC INDICATOR 14 CHANNEL DOWN/UP
3 STOP/EJECT 9 REC/OTR INDICATOR 15 DISC TRAY
4 PLAY/PAUSE 10 POWER INDICATOR 16 OPEN/CLOSE
5 FAST REVERSE 11 TV/VIDEO SELECT 17 PLAY/PAUSE 19 REMOTE SENSOR
6 FAST FORWARD 12 MENU SELECT 18 STOP 20 STANDBY
