Chapter 3 Using the LCD TV
Color temperature Adjusts color components independently to achieve a warm or cool
effect: Cool/Middle/Warm/User
▪ Warm: Increases red tint
▪ Nature : Increases natural tint
▪ Cool : Increases blue tint
▪ User : Allows the user to adjust red, green and blue color
component levels independently.
Noise Reduction Select to reduce the noise level of connected equipment: Medium/
Strong/Off/Low.
VGA Press the OK button to enter the VGA Setting:
▪ H. Position Adjusts the position of the picture left and right in the
window
▪ V. Position Adjusts the position of the picture up and down in the
window
▪ Clock Controls the width of the picture based on the VGA
mode
▪ Phase Controls the signal phase, which can improve focus
clarity and image stability based on the VGA mode
Color Temperature Select Exit
Color Temperature User
R Gain 120
G Gain 120
B Gain 120
VGA Select Exit
H.Position 72
V. Position 31
Clock 127
Phase 31
