Polisport Koolah - How to Remove Your Carrier; Detach Harness to Frame; Unfasten Rack Attachment; Carrier Removal

9
05. ASSEMBLY INSTRUCTIONS
HOW TO REMOVE YOUR CARRIER
EN
Detach the harness to bicycle frame (C) in order to remove
the carrier.
Pull the carrier to take it out of the bicycle rack.
1
3
C
A
To remove the carrier from the rack, unfasten the QST
knob (G1) and lift simultaneously the QST release button
(G2) in order to open the attachment brackets (G3) wider
than the width of the rack.
2
G3
G1
