POLLOGEN TriPollar Stop VX - Page 14

12
FIG.8 Shows the components comprising the TriPollar
®
Stop VX device.
1. DEVICE BODY
2. TREATMENT HEAD
3. ELECTRODE
4. TEMPERATURE SENSOR
5. CONTROL PANEL
6. POWER SUPPLY CONNECTION
7. GREEN/BLUE INDICATION
8. ORANGE INDICATION LIGHT
9. ON/OFF BUTTON
10. LOW RF
11. HIGH RF
12. LOW RF AND DMA
13. HIGH RF AND DMA
14. PROTECTIVE COVER
FIG.8
10. 11.
4.
3.
2.
1.
6.
9.
8.
7.
5.
13.12. 14.
