FIG.8 Shows the components comprising the TriPollar
®
Stop X device.
1. DEVICE BODY
2. TREATMENT HEAD
3. ELECTRODE
4. TEMPERATURE SENSOR
5. CONTROL PANEL
6. POWER SUPPLY CONNECTION
7. GREEN INDICATOR LIGHT
8. ORANGE INDICATOR LIGHT
9. ON/OFF BUTTON
10. LOW RF
11. HIGH RF
12. PROTECTIVE COVER
FIG.8
10. 11.
12.
4.
3.
2.
1.
6.
9.
8.
7.
5.
