Wiring Centre6
MANIFOLD PUMP
OR VALVE
BOILERPOWER
HEAT ENABLE
MAINS
SUPPLY
BOILER
ENABLE
MAINS
L
L
ELS LR E
E
N
N
UFH
5A FUSE
LS AND LR
VOLT FREE
UFH VALVE
Wiring UFH4ZW to SmartStat – 3 x Underoor Heating, 1 x Radiator zone & Hot Water.
(Manifold Valve & Pump connections)
This equipment should be installed by an appropriately
Fully read the instructions for proper wiring before applying power.
The warranty does not cover damage from improper wiring
or installation.
EARTH
END SWITCH AND
BOILER ENABLE
UFM UNDER FLOOR MANIFOLD
LIVE
SWITCH LIVE
NEUTRAL
PUMP
THREE CORE AND
EARTH 1.5 CABLE
To Next Page
