Polypipe UFH4ZW - Ratings

RADIATOR
VALVE
9Model: UFH4ZW
ZONE 4 MANIFOLD PUMP CONTROL SWITCH
SELECT YES FOR UNDERFLOOR HEATING
AND NO FOR ALL OTHER SYSTEMS
N
N
-
-
2A
A1RT2
RT1
RT1
A1
A2
L
L
NO
YES
L
N
ZONE 2
VALVE WITH
ENDSWITCH
HOT WATER STAT
HOT WATER VALVE
RADIATOR
VALVE
NOTE
THE HOT-WATER VALVE LIVE FEED MUST BE
CONNECTED THROUGH THE CYLINDER HIGH
LIMIT THERMOSTAT
ACTUATORS
230V
UFH HEATING HOT WATER
SmartStat
ZONE 3
ZONE 3
L
E
N SL
L
L
N N
ZONE 4
ZONE 4
L
E
N SL
L
L
N N
HOT WATER
HOT WATER VALVE
L
E
N SL
L
E
N GR OR
Ratings
Number of Heating Zones 4
Number of Hot Water Zones 1
Neon Indication Y
DIN Rail Mounting Y
Supply 230v AC 50Hz 1 Phase
Relay Load Max 3 Amp Resistive
Total Load Max 5 Amp Resistive
IP Protection IP20
Installed Dimensions (L,H,D) 384 x 148 x 60mm
Weight 800g
UFHPROGW
N
- A1RT2 RT1 A2
L
SmartStat
