WE6 | Data Sheet - Operation Manual 9/24 WK 420 970 | 01.2021
Coding example:: 4 WE6 E - 32/G24 N Z4 B08 - S1 AB
HOW TO ORDER
1 number of main ports
3 main ports (only for spools A, B) = 3
4 main ports (for the other spools) = 4
2 nominal size (NS)
NS6 = 6
3 spool symbol
spool symbols - see pages 4; 5
4 series number
series 32 = 32
series 30 ÷ 39 - connection and installation
dimensions unchanged
5 spool positioning
with spring return = Ø
without spirng return* = O
without spirng return with detent* = OF
* options available only for spools: A, C, D, EA,
GA, HA, JA, MA, EB, GB, HB, JB, MB)
6 supply voltage of solenoids
12V DC = G12
24V DC = G24
110V DC = G110
110V AC 50Hz
(connector with rectier) = W110R
220V AC 50Hz
(connector with rectier) = W220R
230V AC 50Hz
(connector with rectier) = W230R
230V AC 50Hz
(direct power supply
with AC current) = W230-50
7 manual override
solenoids with manual override = N
solenoids without manual override (only for ver-
sion with inductive position switch M type) = Ø
8 manual lever control*
no lever = Ø
lever positioned vertically = H
lever positioned vertically with a lock = HF
lever positioned diagonally = HS
lever positioned diagonally with a lock= HSF
* options w ith a manual lever control (...H...;
...HS...; ...HF...; ...HSF...) for versions: WE6...A/O...;
...A/OF...; ...B/O...; ...B/OF... with spools: EA, GA,
HA, JA, MA, EB, GB, HB, JB, MB available after
consultation with the Manufacturer
9 electrical connection type
connector ISO 4400 (DIN 43650-A)
without LED = Z4
connector ISO 4400 (DIN 43650-A)
with LED = Z4L
AMP Junior Timer (without mating
connector;only for options G12; G24 ) = J
Deutsch (without mating connector; only
for option G12; G24 ) = D
10 throttle insert (in port P)
without throttle insert = Ø
throttle insert Ø 0,8 = B 08
throttle insert Ø 1,0 = B 10
throttle insert Ø 1,2 = B 12
11 seal type
NBR (for uids on mineral oil base) = Ø
FKM (for uids on phosphate ester base)= V
12 spool position monitoring*
without position switch = Ø
spool position switch type S1 = S1
spool position switch type S2 = S2
spool position switch type M (only for
2-position versions with spring return) = M
* optional versions with a spool position switch
and a manual lever control (options ...H...; ...HS...;
...HF...; ...HSF...) available after consultation with
the Manufacturer
13 monitored spool position
without spool position monitoring = Ø
monitored position 0 - zero = 0
* 3-position versions,
2-position versions with positions (a, 0) or (0, b)
monitored position a = A
* 2-position versions with positions (a, 0) or (a, b)
monitored position b = B
* 2-position versions with positions (a, b) or (0, b)
monitored positions a and b = AB
* 3-position versions
14 further requirements= *
(to be agreed upon with the Manufacturer)
Ø indicates that the box should be left blank.
The symbols in bold are the preferred versions available in short delivery time.
Subplates must be ordered according to data sheet WK 496 480:
• G341/01 - threaded connections G 1/4
• G342/01 - threaded connections G 3/8
• G502/01 - threaded connections G 1/2
The symbols in bold are the preferred versions available
in short delivery time.
SUBPLATES AND MOUNTING SCREWS
Subplates and screws for mounting directional spool valve
M5 × 50 -10.9 in accordance with PN-EN ISO 4762 - 4 pcs./set.
Tightening torque of the screws Md = 9 Nm.
Subplates and mounting screws must be ordered separately.
1 2 3 4 5 6 7 8 9 10 11 12 13 14
WE 6 — —/
