Pontec Multi Clear Set 5000 - Product Details and Assembly; Scope of Delivery and Product Description; Assembly Guide

- EN -
14
Scope of delivery
The parts included in the scope of delivery are inside the container and have to be removed first!
• To open the container → Installation.
5 A
Multi Clear Set 5000/8000
Quantity
1
UVC clarifying unit
• A UVC lamp in the unit irradiates and kills algae in the water.
1
2
Container cover
1
3
Container
• It is delivered containing the UVC clarifying unit and an accessory kit with hose connector and O ring.
1
4
Outlet for fitting a DN 50 HT pipe or a 2" ∅ hose
1
5
− Coarse foam filter, fine foam filter and Japanese filter mat for mechanical cleaning, nitrification and denitrifica-
tion of the water
3
6
Bio-surface elements
• Once colonised by bacteria, they act as filter elements for biologically cleaning the water.
15
7
Inlet elbow with sealing ring
• Connects the outlet of the UVC clarifying unit to the inlet of the filter container.
1
8
Stepped hose adapter with sealing ring
• For connecting the hose to the inlet of the UVC clarifying unit
1
9
Filter pump
1
10
Stepped hose adapter with sealing ring
• For connecting the 20 mm ∅ hose
1
11
Hose
• Connects the UVC clarifying unit to the filter pump
1
Product Description
Properties
Multi Clear Set 5000/8000 is a compact flow-through filter with bio-mechanical filter media and UVC clarifying unit.
• The UVC clarifying unit effectively kills floating algae.
• Multi-chamber filter with two walls separating the chambers that optimise the flow inside the filter, and four different
filter media (Japanese filter mat, coarse and fine foam filters, bio-surface elements).
Intended use
Multi Clear Set 5000/8000, referred to as "unit", may only be used as specified in the following:
• For mechanical and biological cleaning of garden ponds
• For operation with clean water.
• Operate in accordance with instructions.
The following restrictions apply to the unit:
• Do not use in swimming ponds.
• Never use the unit with fluids other than water.
• Never run the unit without water.
• Never operate the UVC lamp outside the casing or use it for any other purposes. The UVC radiation is harmful to the
eyes and skin even in small doses.
• Do not use for commercial or industrial purposes.
• Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
Assembly
The parts included in the scope of delivery are inside the container and have to be removed first!
How to proceed:
5 B
1. Undo the fasteners on both sides of the container cover and lift off the container cover.
2. Take out the UVC clarifying unit. (à Cleaning the UVC clarifying unit)
3. Screw the stepped hose adapter including sealing ring onto the UVC inlet.
4. Screw the inlet elbow including sealing ring onto the UVC outlet.
5. Place the UVC water housing onto the container cover and fasten with both screws, washers and nuts.
– Insert the screws through the guides on the UVC water housing and the holes in the container cover.
6. Place the container cover onto the container and carefully press down until the fasteners engage.
7. Fit the UVC clarifying unit. (à Cleaning the UVC clarifying unit)
